Forney® Frontline™ 825 Smart Battery Charger/Maintainer and Engine Starter, Lead Acid, Lithium-Ion Battery

Call For Availability
SKU: F825
(0)
$0.00
Have A Product Question? Ask Us!
Free Same Day In-Store & Curbside Pickup.
Proudly 100% Employee-Owned & Operated In Marin County.
Forney® Smart Battery Charger/Maintainer and Engine Starter, Lead Acid, Lithium-Ion Battery, 600 Ah Battery, 120 V, 60 Hz, For Use With: 6 V, 12 V Batteries, IP20 Enclosure, 5.34 in H x 10.12 in W x 7.01 in D, Additional Information: 2 A, 10 A, 25 A Charging Current, -4 to 113 deg F Operating Temperature

Features:

  • Multi-function 5-in-1 system: Charge, Maintain, Alternator Test, 13.6V Power Source and Engine Start
  • Up to 25 Amp output for 6 V / 12 V batteries
  • 150 Amp engine-start assist with Boost functionality for weak or cold batteries
  • Force Charge Mode to help start charging deeply discharged batteries below normal detection voltage
  • 13.6 V Power Supply Mode for ECU memory support, accessory power, and bench diagnostics
  • Alternator Test Mode for a quick, voltage-based check of basic charging system health with the engine running
  • Repair Mode designed to help address sulfation and acid stratification in eligible lead-acid batteries
  • Compatible with supported Lead-Acid (AGM, Ca, EFB, Gel, MF, Wet) and Lithium (LiFePO₄) batteries
  • Integrated protection: reverse polarity, overheat, short-circuit, spark-proof connection, open-circuit, and overcharge safeguards
  • Durable IP20-rated steel housing resists oil, grease, chemicals, and shop wear
  • Heavy-duty 10 AWG DC and 12 GA AC cables with approximately 6 ft reach
  • Dimensions: 10.1 × 6.5 × 5.4 in
  • Weight: 6.28 lb
  • ETL, FCC, and DOE certified
  • 3-Year Limited Warranty

Other Attributes:

  • SKU: F825
  • Battery Type: Lead Acid, Lithium-Ion
  • Battery Capacity: 600
  • Power Supply: 120 V, 60 Hz
  • Suitable For Use With: 6 V, 12 V Batteries
  • Enclosure Type: IP20
  • Dimensions: 5.34 in H x 10.12 in W x 7.01 in D
  • Additional Information: 2 A, 10 A, 25 A Charging Current, -4 to 113 deg F Operating Temperature

Documents:

Owners/User Manual
Specification Sheet
